Single Crystal Alumina

High Purity Alumina Series Products

Single Crystal Alumina

Single Crystal Aluminum Oxide

Single Crystal Alumina is easier to form thermal conductivity channel by the line contact and surface contact because heat energy passes directly through single crystal, which has obvious advantages in thermal conductivity.

Our single crystal alumina product has high melting point, good stability, small specific surface area, clean surface, no residual metal impurities and burr, high sphericity, high α phase content, low surface oil absorption value, single crystal transparent, good viscosity reducing effect, excellent thermal conductivity and electrical insulation. It can be used in lithium battery ceramic diaphragm coating, thermal interface materials, thermal conductive engineering plastics, high thermal conductive aluminum coated copper plate, ceramic filter coating, etc.

Specification Details
Typical Properties Units D3-A08 D4-A1
Crystal Structure
α
α
Average Particle Size
(by Bettersize Laser 9300SE)
D50, um
0.5-1.0
0.5-1.0
Loose Bulk Density
g/cm3
0.6-0.7
0.6-0.7
BET Surface Area
m2/g
≤5
≤5
Purity (Al2O3) ≥
%
99.9
99.99
Impurity ≤ (by ICP-OES)
Na
ppm
600
20
Ca
ppm
50
3
Mg
ppm
10
3
Fe
ppm
40
3
Si
ppm
50
10
Packing
(As per customer’s requests)
drum
25kg
25kg
